ConturoMatic TS

Set the bar a little higher - The concept behind all ConturoMatic TS systems consists mainly of two motor-controlled measuring axes. The X-axis carries the test specimen and the Z-axis takes over contour scanning. Both measured value acquisition and control are consistently based on state-of-the-art digital technology. Granite of the highest quality serves as the mechanical basis. Due to the geometrically unambiguous, horizontal position of the probe arm, the inspection of contours and in bores with a diameter smaller than 2 mm up to over 300 mm is possible.

The ConturoMatic allows automated measurement of:

• distances from inner contours to outer contours
• parallelisms
• taper angles
• form errors
• Holes and their inner contours
• Transitions with radii and chamfers
• Measurements of interrupted surfaces
• threads
• Surface roughness

The entire measurement is electronically recorded and documented. And all this with a single measuring device in just a few seconds! A top measuring instrument for quality and sample control in the laboratory and in production.

To the products

Note:

User training is mandatory for this product in order to be able to operate the measuring station safely and to use the software optimally.
